50-Hz rejection
6,25
12,5
25
50
100
200
400
800
1600

14.2.7 Decimal point position

Although eNod4 measurements are integer values it is however possible to store a 'decimal point position' so as to
design a display related to the application. Its value represents the number of decimal digits. If the variable is set to
Zero, it means that decimal point is not used.
Note: the decimal point is directly integrated to SCMBus protocol frames (see § SCMBus).
Admitted values: from 0 up to 7.

14.2.8 Weight unit

It is possible to store the display weight unit into the eNod4.
In transmitter mode, weight unit is a combination of 4 characters and there is no automatic calculation to adjust
weight values if modified.
In belt mode, following values are permitted for weight unit parameter:
•
gram (g)
•
kilogram (kg)
•
ton (t)
Note: the unit is directly integrated to SCMBus protocol frames (see § SCMBus).
A/D conversion rate (meas/s)
60-Hz rejection
7,5
15
30
60
120
240
480
960
1920
User manual SCAIME:
77/108
NU-soft-eNod4B-ETH-E-0716_236709-C.doc
X
1
2
3
5
9
17
33
65
129
