Scaime eNod4-F ETHERNET Software User Manual page 78

Name
Complementary weight to
totalize
Weigth to totalize inflight
value
Learning cycle end of refill
delay
Learning cycle flow rates
reference determination
time
Empty hopper level
Full hopper level
Min permissible instant
flow rate
Max permissible instant
flow rate
Min permissible flow rate
control output
Max permissible flow rate
control output
Inhibit time of flow rates
alarms at start
Inhibit time of flow rates
alarms in service
Maximum time for
refilling start
Time interval for weight
variation control on
refilling
Maximum refilling time
Maximum batch time
Totalizer value (Great WU) 0x008D
Complementary totalizer
value
EtherNet/IP
Modbus
Class/ Attribute
address
(hex/dec)
0x0077 0x69/26
0x0078 0x69/27
0x005C 0x69/4
0x005D 0x69/5
0x0068 0x69/14
0x0A3E 0x69/57
0x006E 0x69/18
0x006F 0x69/19
0x0070 0x69/20
0x0071 0x69/21
0x0072 0x69/22
0x0073 0x69/23
0x006B 0x69/15
0x006C 0x69/16
0x006D 0x69/17
0x0074 0x69/24
/
0x008F /
User manual SCAIME:
NU-Soft-eNod4F-ETH-E-0716_235709-C.doc
Profinet Profinet
Record cyclic
Index Req Code
R: 0x02A8
0x0089
W: 0x02A9
R: 0x04AA
0x008A
W: 0x04AB
R: 0x027A
0x0073
W: 0x027B
R: 0x027C
0x0074
W: 0x027D
R: 0x048E
0x007D
W: 0x048F
R: 0x0404
0x00A9
W: 0x0405
R: 0x0298
0x0081
W: 0x0299
R: 0x029A
0x0082
W: 0x029B
R: 0x029C
0x0083
W: 0x029D
R: 0x029E
0x0084
W: 0x029F
R: 0x02A0
0x0085
W: 0x02A1
R: 0x02A2
0x0086
W: 0x02A3
R: 0x0290
0x007E
W: 0x0291
R: 0x0294
0x007F
W: 0x0295
R: 0x0296
0x0080
W: 0x0297
R: 0x02A4
0x0087
W: 0x02A5
R: 0x04F0
W: /
0x00B4
+ See
modules list
R: 0x02F2
W: /
0x00B5
+ See
modules list
78/113
EtherCAT
Type Access
index/sub-
index
0x4705 / 0x02 Uint RW
0x4705 / 0x03 long RW
0x4701 / 0x01 Uint RW
0x4701 / 0x02 Uint RW
0x4702 / 0x01 Ulong RW
0x4702 / 0x02 Ulong RW
0x4704 / 0x01 Uint RW
0x4704 / 0x02 Uint RW
0x4704 / 0x03 Uint RW
0x4704 / 0x04 Uint RW
0x4704 / 0x05 Uint RW
0x4704 / 0x06 Uint RW
0x4703 / 0x01 Uint RW
0x4703 / 0x02 Uint RW
0x4703 / 0x03 Uint RW
0x4704 / 0x07 Uint RW
0x5006 / 0x01
Ulong RO
(M)
0x5006 / 0x02
Uint RO
(M)
