Scaime eNod4-F ETHERNET Software User Manual page 108

Chapter Name
Calibration of flow rate
Dosing point 6 (control output
value)
Calibration of flow rate
Dosing point 7 (control output
value)
Calibration of flow rate
Dosing point 8 (control output
value)
Calibration of flow rate
Dosing point 9 (control output
value)
Calibration of flow rate
Dosing point 10 (control output
value)
Calibration of flow rate
Dosing
point 1 (flow rate value)
Calibration of flow rate
Dosing
point 2 (flow rate value)
Calibration of flow rate
Dosing
point 3 (flow rate value)
Calibration of flow rate
Dosing
point 4 (flow rate value)
Calibration of flow rate
Dosing
point 5 (flow rate value)
Calibration of flow rate
Dosing
point 6 (flow rate value)
Calibration of flow rate
Dosing
point 7 (flow rate value)
Calibration of flow rate
Dosing
point 8 (flow rate value)
Calibration of flow rate
Dosing
point 9 (flow rate value)
Calibration of flow rate
Dosing
point 10 (flow rate value)
Dosing Kp
Dosing Ti
Dosing Td
EtherNet/
IP
Class
0x69
0x69
0x69
0x69
0x69
0x69
0x69
0x69
0x69
0x69
0x69
0x69
0x69
0x69
0x69
0x69
0x69
0x69
108/113
User manual SCAIME:
NU-Soft-eNod4F-ETH-E-0716_235709-C.doc
EtherNet/
IP
Type
Attribute
(dec)
37 Uint Get Attribute Single / Set Attribute Single
38 Uint Get Attribute Single / Set Attribute Single
39 Uint Get Attribute Single / Set Attribute Single
40 Uint Get Attribute Single / Set Attribute Single
41 Uint Get Attribute Single / Set Attribute Single
42 float Get Attribute Single / Set Attribute Single
43 float Get Attribute Single / Set Attribute Single
44 float Get Attribute Single / Set Attribute Single
45 float Get Attribute Single / Set Attribute Single
46 float Get Attribute Single / Set Attribute Single
47 float Get Attribute Single / Set Attribute Single
48 float Get Attribute Single / Set Attribute Single
49 float Get Attribute Single / Set Attribute Single
50 float Get Attribute Single / Set Attribute Single
51 float Get Attribute Single / Set Attribute Single
52 float Get Attribute Single / Set Attribute Single
Ulon
53 Get Attribute Single / Set Attribute Single
g
Ulon
54 Get Attribute Single / Set Attribute Single
g
Service
