Function
None
Tare
Cancel tare
Zero
Transmit measurement
(in SCMBus/fast SCMBus, in CANopen TPDO2
sending if input 1, TPDO3 sending if input 2)
Continuous measurement transmit
(SCMBus/fast SCMBus only)*
Dynamic zero
Start/Stop refilling**
Start/Stop emptying hopper**
Start/Stop dosing**
Suspend/Resume batch**
Emergency stop
Reset totalization and dosing error counter
Sensor input control
* command operates on logical level
** these commands operates on front in a bistable functioning mode. For example for the Start/Stop refilling
command, the first front initiates refilling, the second stops it.
Note: Most of functions set to logical inputs can also be sent by 'functional commands'; for a precise description see §
'functional commands'.
•
None : the input has no function
•
Tare : a rising (positive logic) or a falling edge (negative logic) causes a tare function to be triggered .
•
Cancel tare : a rising (positive logic) or a falling edge (negative logic) causes the current stored tare to be
erased.
•
Zero : a rising (positive logic) or a falling edge (negative logic) causes a zero function to be triggered.
•
Transmit measurement : only available in CANopen® and SCMBus/fast SCMBus protocols and in
transmitter mode only. A rising (positive logic) or a falling edge (negative logic) triggers a measurement
transmission.
•
Continuous transmit measurement : only available in SCMBus/fast SCMBus protocols. Measurements are
continuously transmitted at a rate defined by the measurement transmission period parameter while the
input is maintained at the chosen level.
•
Dynamic zero : this input activation will cause eNod4 to perform zero function. This zeroing acquisition is
not conditioned by stability criterion and consists in a moving average of measures during an adjustable
parameter dynamic zero acquisition time. The new current zero is not stored permanently and can be
canceled by a reset of the module.
•
Start/Stop refilling : this command operates on front in a bistable functioning mode. In dosing mode, the
first rising or falling edge (according to the configured logic) on this input causes a refilling procedure. The
second one will stop it.
