Chapter Name
Inputs/
Output 4 functioning
outputs
Inputs/
Set point 1 high value
outputs
Inputs/
Set point 1 low value
outputs
Inputs/
Set point 2 high value
outputs
Inputs/
Set point 2 low value
outputs
Inputs/
Set point 3 high value
outputs
Inputs/
Set point 3 low value
outputs
Inputs/
Set point 4 high value
outputs
Inputs/
Set point 4 low value
outputs
Inputs/
1&2 Set points functioning
outputs
Inputs/
3&4 Set points functioning
outputs
Inputs/ Logical input 3 functioning
outputs (optional)
Inputs/ Logical input 4 functioning
outputs (optional)
Inputs/ Analog output functioning
outputs (optional)
Inputs/ External value to control
outputs analog output
Inputs/ Defective measurement
outputs debounced time
Inputs/ Defective measurement
outputs alarm activation time
Commands command register
Commands response register
EtherNet/
IP
Class
0x67
0x67
0x67
0x67
0x67
0x67
0x67
0x67
0x67
0x67
0x67
0x67
0x67
0x67
0x67
0x67
0x67
0x68 (104d) / Instance 1
0x68
0x68
105/113
User manual SCAIME:
NU-Soft-eNod4F-ETH-E-0716_235709-C.doc
EtherNet/
IP
Type
Attribute
(dec)
4 MSB Byte Get Attribute Single / Set Attribute Single
5 Long Get Attribute Single / Set Attribute Single
6 Long Get Attribute Single / Set Attribute Single
7 Long Get Attribute Single / Set Attribute Single
8 Long Get Attribute Single / Set Attribute Single
9 Long Get Attribute Single / Set Attribute Single
10 Long Get Attribute Single / Set Attribute Single
11 Long Get Attribute Single / Set Attribute Single
12 Long Get Attribute Single / Set Attribute Single
13 LSB Byte Get Attribute Single / Set Attribute Single
13 MSB Byte Get Attribute Single / Set Attribute Single
14 LSB Byte Get Attribute Single / Set Attribute Single
14 MSB Byte Get Attribute Single / Set Attribute Single
15 Uint Get Attribute Single / Set Attribute Single
16 Uint Get Attribute Single / Set Attribute Single
17 Uint Get Attribute Single / Set Attribute Single
18 Uint Get Attribute Single / Set Attribute Single
1 Uint Get Attribute Single / Set Attribute Single
2 Uint
Service
Get Attribute All
Get Attribute Single
