6.4 EtherNet/IP LED

State of the NS (Network Status) bicolor LED is described in the table below:
Color
Blinking
Green
Always on
Blinking
Red
Always on
Red / Green Blinking
- Always off
State of the MS (Module Status) bicolor LED is described in the table below:
Color
Blinking
Green
Always on
Blinking
Red
Always on
Red / Green Blinking
- Always off
State of the ACT / LINK ETH1 and ETH2 network RJ45 connector LED:
Color
LINK Always on
(Eth1 & Eth2)
Always off
Green
ACT On
(Eth1 & Eth2)
Always off
Yellow

6.5 I/O scanning / implicit messaging

eNod4 Target (Adapter) depending version could consumes up to two registers (4 bytes without header) of Output
data (from the network's point of view) through Assembly Instance 0x64 (100) with a Cyclic transport trigger type and
point to point connection type.
With no IO+ option, data exchanged is the command register which is the attribute 1 of device application-specific
0x68 class.
State
NO CONNECTIONS: device has no connections established, but has
obtained an IP address
CONNECTED (at least one connection is established)
CONNECTION TIMEOUT: one or more of the connections in which this
device is a target has timed out.
This shall be left only if all timed out connections are reestablished or
if the device is reset.
DUPLICATE IP: the device has detected that its IP address is already in
use
Autotest at power on
Device not powered or defective
State
STANDBY: the device has not been configured
DEVICE OPERATIONAL: Device is operating correctly
MINOR FAULT:
the device a detected a recoverable minor fault
MAJOR FAULT:
the device a detected a non-recoverable major fault
Autotest at power on
Device not powered or defective
State
A physical connection to the Ethernet exist
Device not connected to the Ethernet
The device sends/receives Ethernet frames
No traffic on the Ethernet
