Appendix A: Technical Data
A Technical Data
A.1 General Specifications
Model name
Order code
Dimensions (L x W x H)
Weight
Operating temperature
Storage temperature
Humidity range
Power supply
Current consumption
Galvanic isolation
Mechanical rating
Mounting
Certifications
A.2 CAN Interface
Maximum baud rate
CAN connector
CAN specification
A.3 PROFINET IRT Interface
PROFINET specification
PROFINET functionality
Isochronous cycle times
Maximum I/O data
Ethernet
Anybus ® Communicator ™ CAN PROFINET
Anybus Communicator CAN PROFINET IRT (2.32)
AB7328
120 x 75 x 27 mm
150 g
-25 to +55 °C (IEC 60068-2-1 and IEC 60068-2-2)
-40 to +85 °C (IEC 60068-2-1 and IEC 60068-2-2)
5–95 % RH, non-condensing (IEC 60068-2-30)
24 V ±10 % DC regulated power source
Typical: 100 mA @ 24 VDC
Maximum: 250 mA @ 24 VDC
Yes, on both network sides
IP20, NEMA rating 1
DIN rail (EN 50022)
Network shield conductance via DIN rail
CE
1 Mbit/s
D-sub 9 Male (included)
CAN 1.0, 2.0A and 2.0B
2.32
Isochronous Real-Time (IRT) communication
Conformance supporting Class A, B and C
Media Redundancy Protocol (MRP) support
Discovery and Configuration Protocol (DCP) support
Acyclic Data exchange (Record Data Requests)
Asset Management
0.250 ms to 16 ms
Up to 512 byte in each direction
100 Mbit/s, full duplex (fixed)
Dual port cut-through switch, RJ45 connectors
Ethernet Transport Provider support
