PROFINET Asset Management
6.7

Uploading the Asset Management File to the FTP Server

Use Windows Explorer or a standard FTP client to transfer the asset management file to the FTP
server.
When the superposed parameter channel function is enabled, transfer the asset management
file via a PLC connected to the network where the gateway is installed.
6.7.1 Transferring the Asset Management File from Windows Explorer
Transfer the asset management file, XML or binary file, to the FTP server using Windows Explorer.
Before You Begin
Use only one of the file formats, XML format or binary format.
Only upload one single file on the FTP server.
• Name the asset management file: asset_mgmt
• The default port is FTP port 21.
• Make sure that the gateway and your computer are connected to the PROFINET network to
be used.
Procedure
Fig. 23 The FTP Server root folder
1. Open an Windows Explorer Window.
2. Click to select the Address bar.
3. Enter ftp://Username:Password@IPaddress.
– Replace "Username" and "Password" with a valid username and password combination.
– Replace 'IPaddress' with the IP address of the PROFINET interface.
4. Press Enter.
