Technical Data

3 Technical Data
3.1

General Specifications

Model name
Order code
Dimensions (L x W x H)
Weight
Operating temperature
Storage temperature
Humidity range
Power supply
Current consumption
Galvanic isolation
Mechanical rating
Mounting
Certifications
3.2

Serial Interface

Serial application Interface
Maximum number of stations
Protocol: Modbus RTU
Protocol: ASCII/Vendor Specific
Protocol: Rockwell DF1
Anybus ® Communicator ™ Startup Guide
Anybus Communicator IIoT
AB7079-B
120 x 75 x 27 mm
150 g
0 to +55 °C (IEC 60068-2-1 and IEC 60068-2-2)
-40 to +85 °C (IEC 60068-2-1 and IEC 60068-2-2)
5–95 % RH, non-condensing (IEC 60068-2-30)
24 V ±10 % DC regulated power source
Typical: 100 mA @ 24 VDC
Maximum: 200 mA @ 24 VDC
Yes, on both network sides
IP20, NEMA rating 1
DIN rail (EN 50022)
Network shield conductance via DIN rail
See datasheet at www.anybus.com/support
Selectable RS-232, RS-422, RS-485
31 nodes via RS-422 or RS-485
Modbus RTU Master - Query/Response
Request/Response or Produce/Consume
DF1 Master
