PROFINET Asset Management
Record Data
Data about the assets on the non PROFINET network is recorded and stored in an XML file or an
binary file.
Read Data
Each time an instance is requested the asset management data is read out over the PROFINET
network.
The recorded asset management data can be downloaded to a computer connected to the
PROFINET network.
6.3

Supported File Formats

The following file formats are supported for the asset management file.
Format
XML
Binary file
Little-endian
6.4

Supported Asset Management Records

Supported asset management records:
• Unique ID
• Location
• Hardware Revision
• Annotation
• Order ID
• Serial Number
• Software Revision
• Serial Number
Anybus ® Communicator ™ CAN PROFINET ® IRT (2.32) User Manual
Version
XML Version 1.0
N/A
