Installation and Operating Instructions | idOil-D30
ATEX and IECEx
Ex classification
Special terms (X)
Exi connection values
Maximum values in explosion group IIB
See system diagram Appendix A
Manufacturing year:
Please see the serial number on the type
plate.
VTT 17 ATEX 006X
IECEx VTT 17.0004X
II 1 G Ex and IIB T5 Ga
Ta = -25°C...+60°C
Ui = 16 V, Ii = 80 mA, Po = 400 mW
Ci < 4.0 nF, Li < 1.6 mH
xxxxxxx x xxx xx YY x
where YY = manufacturing year
(e.g. 18 = 2018)
48/51
DOC001602-EN-4
