Relay settings
Restoring factory settings is described in Section Settings.
6.3.

Commissioning through the browser-based interface

The commissioning process can also be performed through the control unit's built-in
browser-based user interface. For this, you must establish a local WLAN connection
between the idOil control unit and a terminal device, such as a smartphone, PC or tablet.
More details on using the browser-based interface is provided in the section Using the
browser-based interface.
6.3.1.

Establishing a WLAN connection

Connect power to the idOil control unit.
The display presents the message shown in
the figure: NO SENSORS.
Press the reset button briefly.
A symbol indicating a WLAN network
connection is shown in the upper left corner
of the display.
If the device power is already on, press the
reset button twice; the first push activates
the backlight and the second press activates
the WLAN connection.
Establish a WLAN connection between the idOil control unit and terminal device as
follows:
Connected sensors
function
Relay 1
maintenance period
alarm
relay is restored
when alarm is reset
Connected sensors
function
Relay 2
maintenance period
alarm
relay is restored
when alarm is reset
All sensors connected to the
control unit
function upon sensor alarm
and sensor fault
off
no
All sensors connected to the
control unit
function upon sensor alarm
and sensor fault
off
no
Figure 21. WLAN network on
DOC001602-EN-4
