Installation and Operating Instructions | idOil-D30
ATEX and IECEx
Ex classification
Special terms (X)
Exi connection values
Maximum values in explosion group IIB
See system diagram Appendix A
Manufacturing year:
Please see the serial number on the type
plate.
9.2.

Technical specifications idOil-LIQ high liquid level sensor

TECHNICAL SPECIFICATIONS idOil-LIQ
Operating principle
Enclosure
Weight
Temparature
Supply voltage
Cable
EMC
ATEX and IECEx
Ex classification
Special terms (X)
Exi connection values
Maximum values in explosion group IIB
See system diagram Appendix A
Manufacturing year:
Please see the serial number on the type
plate.
VTT 16 ATEX 018X
IECEx VTT 16.0005X
II (1) G [Ex ia Ga] IIB
Ta = -30 °C...+60 °C
Uo = 14.5 V, Io = 78 mA, Po = 367 mW,
R = 243 Ω
Output voltage's characteristic curve is
trapezoidal
Co = 4.0 µF, Lo = 16.7 mH
xxxxxxx x xxx xx YY x
where YY = manufacturing year
(e.g. 18 = 2018)
Vibration
Enclosure class: IP 68
Materials: PVC, aluminium, PA, CR,
Viton
300 g (incl. 5 m cable)
Operation: 0ºC...+60ºC
Environment: -30ºC...+60ºC
approx. 12 V DC
2
2 x 0.75 mm PUR
IEC/EN 61000-6-2
IEC/EN 61000-6-3
VTT 17 ATEX 005X
IECEx VTT 17.0003X
II 1 G Ex and IIB T5 Ga
Ta = -25°C...+60°C
Ui = 16 V, Ii = 80 mA, Po = 400 mW
Ci < 5.2 nF, Li < 1.6 mH
xxxxxxx x xxx xx YY x
where YY = manufacturing year
(e.g. 18 = 2018)
46/51
DOC001602-EN-4
