Please take note: This Quick Guide is not a replacement for the manual. It is only a brief overview of the functions of the alarm system. Detailed information about the alarm system can be found in the manual. The correspon- ding safety chapter of the manual is an integral component of this document.
Connection to Sensors in Potentially Explosive Areas In oil/petrol separator systems, only sensors that are approved for installation in potentially explosive areas can be connected. The safety class of the external equipment must correspond to the safety class prescribed for the entire system. Sensor Cable Sensor cables cannot be run in cable or conductor bundles together with other circuits.
1 Installing the idOil-LIQ high liquid level sensor The sensor is normally in air, and it issues an alarm when the sensing element is submerged in liquid. The sensor is installed at a suitable height above the standard liquid level (L) so that the overflow alarm is activated once the liquid level reaches the sensing element.
Page 7
2 Installing the idOil-OIL oil sensor The sensor must be submerged at the desired installation depth when the liquid is at the separator’s standard liquid level (L). Notice manu- facturer´s instructions for oil separators. 1 Oil sensor idOil-OIL A Air B Oil C Water L Standard liquid level...
3 Installing the idOil-SLU sludge sensor The sensor must be submerged at the desired installation depth when the liquid is at the separator’s standard liquid level (L). Notice manu- facturer´s instructions for oil separators. 1 Sludge sensor idOil-SLU A Air B Oil C Water D Sludge...
Page 9
4 Connections After complete installation of control unit, sensors, relays and installing of protection plate the power supply may be connected. 1 idOil-20 control unit 2 LCJ cable connector 3 idOil-LIQ high liquid level sensor 4 idOil-OIL oil sensor 5 idOil-SLU sludge sensor...
Page 10
Connection with three sensors, two relays and supply voltage 1 Supply voltage (connectors L1, N, PE) 2 Sensor connections (connectors 9-14) 3 Relay 1 connection (connectors 3,4,5) Relay 2 connection (connectors 6,7,8) 4 Extension of cable with LCJ cable connectors 5 Protection cover...
Page 11
5 Commissioning High level sensor alarm indicator light Oil sensor alarm indicator light Sludge sensor alarm indicator light Fault indicator light Supply voltage indicator light Alarm reset and test button The front cover of the housing must be removed. Make sure that the protection cover (8) is properly attached.
Page 12
Labkotec reserves the rights to alterations without prior notice. Due to policy of continuous improvement in R&D, technical specifications may change. Installation shall always be made as documented in manufacturer´s instructions. Labkotec Oy Myllyhaantie 6 FI-33960 Pirkkala FINLAND Tel. int. +358 (0)29 006 260 Fax int.
