Installation and Operating Instructions | idOil-D30
9.
Technical specifications
9.1.
Technical specifications for the idOil control unit
TECHNICAL SPECIFICATIONS idOil-D30
Dimensions
Enclosure
Weight
Operating environment
Operating voltage
Power consumption
Sensors
Relay outputs
Display
User interface
Electrical safety
EMC
RED
157 mm x 86 mm x 58 mm (w x h x d)
IP20, material: polycarbonate (cover)
and Noryl (bottom)
250 g
Temperature: -30ºC...+60ºC
Max. elevation above sea level 3,000 m
Relative humidity RH 100%
100–240 V AC ± 10%, 50/60 Hz
Fuses IEC 60127-4:
0.5 A @ 250V AC and 125V DC
0.04 A @ 250V AC and 125V DC
The fuse cannot be replaced.
The device does not have a mains
switch.
Max. 12 VA
Digital Labkotec idOil sensors
5 A, 250 V AC / 30 V DC, 100 VA
Potential-free changeover contacts.
Character-based 20x4 LCD screen for
displaying alarm and fault states.
Browser-based
user
displaying alarm and fault states and
configuring the device over a Wi-Fi
connection (2.4GHz; 802.11 b/g/n)
IP address: 192.168.0.1
IEC/EN 61010-1, Class I, CAT II
UL 61010-1
CAN/CSA-C22.2 NO. 61010-1-12
IEC/EN 61000-6-2
IEC/EN 61000-6-3
EN 300 328
45/51
interface
for
DOC001602-EN-4
