Table B‐3: Ports Added when the "Transceiver Control and Status Ports" Option is Enabled
(N is the number of the channel) (Cont'd)
Port
gtN_eyescantrigger_in
gtN_eyescanreset_in
gtN_eyescandataerror_out
gtN_rxrate_in
gtN_rxdisperr_out
gtN_rxnotintable_out
gtN_rxresetdone_out
gtN_txresetdone_out
Port Changes From v12.0 to v12.1
Table B-4 summarizes the port changes and the suggested solutions.
Table B‐4: Ports Added From v12.0 to v12.1
Port
gtN_txpmareset_in
gtN_txpcsreset_in
gtN_rxpmareset_in
gtN_rxpcsreset_in
gtN_rxpmaresetdone_out
gtN_rxbufstatus_out[2:0]
gtN_txphaligndone_out
gtN_txphinitdone_out
gtN_txdlysresetdone_out
XAUI v12.3 Product Guide
PG053 April 6, 2016
Direction Reason for Change
IN Added Transceiver Control and
Status Ports
IN Added Transceiver Control and
Status Ports
OUT Added Transceiver Control and
Status Ports
IN Added Transceiver Control and
Status Ports
OUT Added Transceiver Control and
Status Ports
OUT Added Transceiver Control and
Status Ports
OUT Added Transceiver Control and
Status Ports
OUT Added Transceiver Control and
Status Ports
Direction Reason for Change
Added Transceiver Control and
in
Status Ports.
Added Transceiver Control and
in
Status Ports.
Added Transceiver Control and
in
Status Ports.
Added Transceiver Control and
in
Status Ports.
Added Transceiver Control and
out
Status Ports.
Added Transceiver Control and
out
Status Ports.
Added Transceiver Control and
out
Status Ports.
Added Transceiver Control and
out
Status Ports.
Added Transceiver Control and
out
Status Ports.
www.xilinx.com
Appendix B: Migrating and Upgrading
Proposed Solution
Assign default value: 0
Assign default value: '0'
Assign default value: open
Assign default value: B"000"
Assign default value: open
Assign default value: open
Assign default value: open
Assign default value: open
Proposed Solution
Assign default value: '0'.
Assign default value: '0'.
Assign default value: '0'.
Assign default value: '0'.
(GTH, GTP transceivers)
Assign default value: open.
Assign default value: open.
Assign default value: open.
Assign default value: open.
Assign default value: open.
