Applications - Xilinx LogiCORE IP Product Manual

Applications

Figure 1-2 shows the XAUI core connecting a 10-Gigabit Ethernet MAC to a 10-Gigabit
XPAK optical module.
X-Ref Target - Figure 1-2
FPGA
User Logic
(Ten Gigabit
Ethernet
MAC)
Figure 1‐2:
After its publication, the applications of XAUI have extended beyond 10-Gigabit Ethernet to
the backplane and other general high-speed interconnect applications.
typical backplane and other general high-speed interconnect applications.
XAUI v12.3 Product Guide
PG053 April 6, 2016
XAUICore
low speed management signals
XAUI Connecting a 10-Gigabit Ethernet MAC to an Optical Module
