Easy Config

1. Power on the unit and wait for the Link Quality LEDs to light up and go out
again, then immediately press and release the MODE button.
2. Press MODE repeatedly to cycle through the Easy Config modes until the
desired mode is indicated by the A-B-C-D LEDs.
3. Within 20 seconds of step 2, press and hold MODE for 2 seconds. When the
button is released the unit will restart in the selected mode.

Easy Config Modes

Mode Role
2 —
3 —
4 Client
5 WLAN AP
6 Bluetooth NAP
7 WLAN AP
8 Bluetooth NAP
10 —
Modes 5 – 8 will scan for units in mode 4. Detected units will be reconfigured as
clients, and the scanning unit will restart as an access point. The clients will then
restart and connect to the access point.
Modes 7 and 8 will additionally apply PROFINET optimization to all the units.
PROFINET messages will then have priority over TCP/IP frames.
Mode Timeout
• Modes 5 – 8 will time out after 120 seconds. Apply the mode again to repeat
the scan.
• Mode 4 will listen for 120 seconds or until receiving a configuration.
Anybus ® Wireless Bridge II
Description
Reset configuration to factory defaults.
Reset IP settings to factory defaults.
Wait for automatic configuration.
Configure units in mode 4 as clients.
Restart as access point and connect clients.
Configure units in mode 4 as clients.
Restart as access point and connect clients.
Apply PROFINET optimizations to all units.
Apply PROFINET optimizations and restart.
The IP address of a client may be changed by the configuration from the
access point. Active browser sessions could therefore be lost.
™ Startup Guide
