Preparation
1.3 Model Name – Certification Identifier
The model name is used to identify the product for various certifications. It con-
sists of a model prefix followed by two designators for the specific interface con-
figuration and functionality.
Prefix
Interface configuration
Functionality
Example: AWB3AA = Anybus Wireless Bridge II with internal antenna, Ethernet
networking and digital input.
Anybus ® Wireless Bridge II
AWB3
A
B
A
B
™ Startup Guide
Anybus Wireless Bridge II
Internal antenna (Closed Type), interfaces:
Dual M12
External antenna (Open Type), interfaces:
Dual M12, RP-SMA
Ethernet with digital input
Ethernet w/o digital input
SCM-1202-013/SP2167-EN 1.7
4 (16)
