Led Indicators - HMS Anybus Wireless Bridge II Startup Manual

Installation
2.3

LED Indicators

PWR
WLAN
LAN
BT
RSSI (WLAN Client) / Link Quality (Bluetooth PANU)
A
A B
A B
A B
Additional LED indications are used when the unit is in Recovery Mode.
See Recovery Mode LED Indications, p.
Anybus ® Wireless Bridge II
Off
Green
Off
Blue, blinking
Blue
Blue, flickering
Purple, blinking
Purple
Red
Off
Yellow
Yellow, flickering
Off
Blue, blinking
Blue
Blue, flickering
Purple
Red
No connection
RSSI/Link Quality < 25 %
RSSI/Link Quality 25–50 %
RSSI/Link Quality 50–75 %
C
D RSSI/Link Quality > 75 %
C
™ Startup Guide
No power
Normal operation
WLAN disabled or no power
Access Point: No clients, awaiting connections
Access Point: Connected to at least one client
Client: Connected to access point
WLAN data activity (when connected)
Client: Scanning for access points
Client: Connecting to a detected access point
Unrecoverable error
No Ethernet connection
Ethernet link present
Ethernet data activity (when connected)
Bluetooth disabled or no power
NAP: No clients, awaiting connections
NAP: Connected to at least one PANU client
PANU: Connected to NAP
Bluetooth data activity (when connected)
PANU: Trying to connect to NAP
Unrecoverable error
12.
SCM-1202-013/SP2167-EN 1.7
8 (16)
