2 Paper load and thread
To prepare the paper for printing:
1 Bring the paper up and over the print-
ing base.
2 Slide the paper towards the rear of
the printer bridge, as shown in the
diagram.
Check the tension on both sides
of the paper. The tension should
be uniform and sufficient to keep
the paper taut.
3 Leave approximately 0.5 meters
(19.68 inches) of paper hanging from
the rear of the plotter.
68
2
1
2
1
3
2
2
GERBERplotter MP Series User Manual
Step 2 of 5
