3
Left-side panel
CN229 + CNIIO (Bag 2)
Fit the left-side panel (CN229).
Attached to the left-side panel is a bag with eight bolts and washers
labeled CN110 (Bag 2).
CN229
3
2
Raise the left side of CN231.
1
Position the mounting notches in CN231 over the mounting bolts
2
on CN229.
Tilt CN229 until it is positioned perpendicular to CN231.
3
Install eight bolts and washers using the No. 4 Allen key and Bag
4
2.
GERBERplotter MP Series User Manual
No.4 Allen key
CN231
1
4
CN110 (Bag 2)
Step 3 of 17
3
15
