7.2.1 Firmware back-up

The printer firmware tab lets you make a copy of the firmware security of the plotter or update the firmware from
another file. Make a backup copy of the firmware security before updating the firmware, so you can revert to the
backup if needed.
To perform a backup:
1 Click the ellipsis (...) button to open the FW UP dialog
box.
2 In the FW UP dialog box, choose the location where
you want to save a copy of the firmware security. As-
sign a name to the file (in this case, backup.bin).
3 Click Save to open the original Printer Manager dialog
box.
4 If the plotter is turned on and connected to Server Man-
ager, click the backup icon to transfer the plotter firm-
ware to the computer and create a file in the selected
location.
