This dialog box lets you rotate the file 90 degrees clockwise or counterclockwise, mirror the file horizontally or
vertically, and magnify the image. You can include your changes in the job queue.
Rotation (left/right). Flip (vertical/horizontal).
Double-click a job to preview the contents of a job that has already been added to the job queue.

6.1.10 History

Use the History / Queue files status tabs to access a table that displays all the tasks completed by User Manager.
This table displays the names of the files sent to the plotter, the IP address and the port used to connect with Server
Manager, the date and time they were added to the job queue, and a status indicator.
Possible status descriptions shown in history
Excess width error
Rasterizing error
Printing error
Waiting to raster
Waiting for printing
Printing
Printed
Removed
Can't send file
Server closed before raster
134
Magnify image.
The file exceeds the maximum allowed width for the plotter.
It was not possible to rasterize this file (page 127).
An error occurred while sending the job, probably because it did not finish
printing.
File waiting to be rasterized.
Job waiting to be sent to the plotter.
Job is printing.
Job printed correctly.
Job removed from print queue.
The file cannot be sent to the server, probably because it has been stopped,
paused or User Manager cannot connect to it.
The server has stopped before finishing the rasterizing process.
Place job in queue.
