1
Disassemble sides
CN229
Separate panels and covers.
Assemble the right- and left-side panel and covers.
1
Push cover tabs from the bottom.
2
Pull the cover.
3
Remove the cover.
4
GERBERplotter MP Series User Manual
CN227
1
Step 1 of 17
2
3
13
