6.1 User Interface (User Manager)

User Manager is the software application that sends print jobs to the plotter.
The installation of User Manager establishes a default connec-
tion with a Server Manager that manages a plotter connected
to a lone computer. For other configurations, see section 3.3.5
User Manager (configuration settings) and 3.3.6 User Manager
Configuration Samples.
To start working with a plotter, it must first be turned on and
connected to a computer that runs the Server Manager. You can
access User Manager directly from your desktop or through the
Windows Start menu.
For a proper connection between client and server, start Server Manager first.
User Manager tries to connect with Server Manager and indicates an error if Server Manager
is not running.
If the main window of Server Manager is not displayed, check whether it is running by look-
ing at the taskbar. If the Server Manager icon is there, you can access the server by double-
clicking it.
Server Manager running (minimized).

6.1.1 User Manager main window

The User Manager main window is arranged into various sections: Main menu, status indicators, and job queue.
Main menu
Status indicators
Print queue
GERBERplotter MP Series User Manual
Main Menu
Jobs queue.
