6.1.11 Sending jobs automatically

User Manager has a mode to insert a job in the print queue automati-
cally.
You can select a folder that the program monitors constantly. Files
1
that are copied into this folder are analyzed and, if User Manager
recognizes the format, they are rasterized and added to the job
queue using default parameters (see 6.1.3 Sending jobs to the plot-
ter).
You can also use the pattern subfolder for small jobs. You can
2
manually group them together to generate composite jobs (see the
Pattern print from folder section in 6.1.4 Default settings), or this
can be done automatically if the files fulfill certain requirements
specified in the configuration.
Files that are copied into the automatic
sending folder are removed from the fold-
er when they are sent to the plotter.
Configure the different automatic send options:
To configure the different automatic send options,
1
open the Connection settings dialog box (see 3.3.4
User Manager (connections manager)).
You can access the Automatic print dialog box
2
through the corresponding tab.
If the Advanced user option is not enabled, you
3
can only use the dialog box to change the location
of the Automatic send folder (located by default
on the Windows desktop) and to activate pattern
detection.
136
Location of automatic send folder.
Select the folder dialog box.
GERBERplotter MP Series User Manual
Automatic pattern
recognition enabled.
