Connections
After the electronic panel has been installed, connect the following cables.
Connect the earth cable from the net filter to the adjacent earth connection.
1
Connect the ribbon cables from the printer bridge to CON8, CON9, and CON10. CON10 is only available
2
on plotters with four print heads.
Connect the black cable from the upper motor to the CON3 connector.
3
Connect the cable from the top cover to the CON43 connector on the main board.
4
Connect the RFID cables to CON28 (red coded cable) matching the red coded connector on the main board.
5
Connect the cable from the printer bridge to the CON29 connector.
6
Connect the cable for the paper advance encoder wheel to the CON5 connector. The yellow coded cable
7
must match the yellow connector on the main board.
Connect the black cable from the lower motor to the CON22 connector.
8
If your plotter has a giant collector bar option (GCB), connect the GCB cable to CON4.
9
