1.1 About the GERBERplotter MP Series

The GERBERplotter MP Series are ideal for plotting in an ultrawide format, yet are small enough to fit into any de-
sign pattern making area. These plotters are quiet, easy to install, use minimal floor space, and can be conveniently
set against a wall. The GERBERplotter MP Series inkjet plotters are easy to use and feature high reliability, accu-
racy, and low operational costs. They are compatible with all Gerber products and offer a Windows-based graphical
interface for intuitive control and status messaging.
Technical datasheet
Power consumption
Power supply
Interface
Inkjet technology
Inkjet heads
Paper (g)
Paper (oz)
Noise level
File formats accepted
Package dimensions (1.8 m plotter)
Package dimensions (2.2 m plotter)
Net Weight (1.8 m plotter)
Crated Weight (1.8 m plotter)
Net Weight (2.2 m plotter)
Crated Weight (2.2 m plotter)

1.2 Customer support

Contact a Service Support Center with support or technical questions.
Please have the following information available prior to contacting Gerber support.
Service Support Center
Center phone number
Sales order number
Purchase date
Product name and type
Optional equipment used
GERBERplotter MP Series User Manual
70W minimum
85/264V auto switch
USB 2.0 & LAN (optional)
HP 1645 compatible | Xaar (optional)
HP 1 7 2 / 3 / 4 | Xaar 1 / 2
Starting at 20 g/m
2
Starting at 0.70548oz/m
< 40 dB
HPGL / HPGL2 / ISO
2820 mm x 540 mm x 700 mm
(111.023 in. x 21.25 in. x 27.55 in.)
3220 mm x 540 mm x 700 mm
(130.00 in. x 21.25 in. x 27.55 in.)
112 kg (247 lbs.)
142 kg (313 lbs.)
118 kg (260 lbs.)
152 kg (335 lbs.)
