4.6.2

Electrical data: three-phase pumps

When you start a cold pump, the motor will draw the start-up current shown in
current will then reduce quickly as the motor reaches rated rotational speed. Within 5 minutes, as the oil and pump
warms up, the current drawn will slowly reduce to the full load current specified in
When you start a warm pump, the motor will draw the start-up current shown in
current drawn will then immediately fall to the full load current specified in
Electrical short-circuit and ground-fault protection of the pump will be provided by fitting Class CC fuses of the values
shown in Table 6 at the point of connection to the supply. If these are not available in your country of use, Type aM
European fuses of the same rating can also be used.
Nominal
Pump
supply (V)
EM40 400
EM80 400
EM175 400
EM275 400
© Edwards Limited 2008. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Table 6 - Electrical data (three-phase pumps)
Frequency Power
(Hz) (kW)
50/60 1.1
50/60 2.2
50/60 5.5
50/60 7.5
Table 6 for several seconds. The
Table 6.
Table 6 for up to 0.5 seconds. The
Table 6.
Full load Start-up
current (A) current (A)
2.55 11
4.8 14
11 52
14.5 52
A652-18-880 Issue C
Recommended
fuse rating (A)
5
10
20
25
Page 11
