Component References - ST STM32L152-EVAL Application Note

Reference design
7.2

Component references

Table 4.
Id Components name
1 Microcontroller
2 Capacitors
3 Capacitor
4 Capacitor
Table 5.
Id
R2, R4, R5,
R7, R8
R6
R1
R3
C3, C5,
C10, C11,
C12, C13,
C14, C15
C1, C2
C7, C8
C4, C6
C9
X2
X1
CN1
SW1, SW2
B1
26/30
Mandatory components
Reference
STM32L152VB(T6)
100 nF
10 µF
1 µF
Optional components
Components name
Resistor 10 kΩ
0 Ω
Resistor
0 Ω
Resistor
0 Ω
Resistor
Capacitor 100 nF
Capacitor 6.8 pF
Capacitor 20 pF
Capacitor 1 µF
Capacitor 10 µF
Quartz 8 MHz
Quartz 32 kHz
JTAG connector HE10
Switch 3V3
Push-button B1
Doc ID 17496 Rev 5
Quantity
1 100-pin package
Ceramic capacitors (decoupling
3 ... 6
capacitors)
1 Ceramic capacitor (decoupling capacitor)
Ceramic capacitor (LCD booster or
2
decoupling capacitor)
Reference Quantity
9
1
2
1
8
2
2
2
1
1
1
1
2
1
Comments
Comments
Pull-up and pull-down for JTAG and
Boot mode.
Used for HSE: the value depends on
the crystal characteristics.
A typical value is 390 Ω .
Used for LSE: the value depends on
the crystal characteristics.
This resistor value is given only as a
typical example.
For low pass filter
Ceramic capacitor
Used for LSE: the value depends on
the crystal characteristics. Fits for
MC-306 32.768K-E3, which has a
load capacitance of 6 pF.
Used for HSE: the value depends on
the crystal characteristics.
Ceramic capacitors (decoupling
capacitors)
Ceramic capacitors (decoupling
capacitors)
Used for HSE
Used for LSE
Used to select the right boot mode
AN3216
