3-2

3.2 Environmental Conditions

3.2.1 Temperature

Condition
Operating
Transportation
Storage

3.2.2 Humidity

Condition
Operating
Transportation
Storage

3.3 Power Line Requirements

3.3.1 DC IN

Condition
Input Voltage Range
Connector

3.3.2 PoE

Condition
Input Voltage Range
Connector
GGS-000549-01E
(in windless condition)
(wind speed is 1 m/s)
Reference
Requirements
Up to 100% all-weather (IP66)
Up to 100%
Up to 100%
Requirements
–48.0 V DC (–40.5 to –57.0 V DC)
ETSI EN 300 132-2
molex® Mega-Fit Connector [172064-0004]
Requirements
41.0 to 57.0 V DC
LTPoE++ Compliant
RJ-45 Connector
SYSTEM PERFORMANCES
Requirements
–33 to +45°C
–33 to +50°C
–33 to+40°C by ETSI EN 300 019-1-4
Class 4.1 in the EU market
–40 to +70°C (ETSI EN 300 019-1-2 Class 2.3)
–25 to +55°C (ETSI EN 300 019-1-1 Class 1.2)
PASOLINK EX A
I
: S
DVANCED PECIFICATION
