5. Specify the parameters, then click the OK button.
Figure 4-4 L2 Loopback Control >> Step 2 Option Window
Parameter Value
Loopback Port Loopback
Mode
VLAN Loopback
L2 Loopback Loopback1
Loopback2
Release Time * No Limit
90 [s]
180 [s]
300 [s]
60 [min]
12 [h]
6.
Figure 4-5 Warning Dialog Box
7.
GGS-000548-01E
Table 4-1 L2 Loopback Control Parameters
Description
Operates a port loopback.
Operates a VLAN loopback.
Loops back at the near side of the L2 Switch.
Loops back at the far side of the L2 Switch. In this mode, the available
frame size to loop back is the maximum size that is specified by Max
Frame Size Setting (see 8.2.2 Max Frame Size Setting in the Set
Network and System Provisioning manual) minus 16 bytes.
Keeps L2 Loopback operations.
Sets 90 seconds to wait before restoring.
Sets 180 seconds to wait before restoring.
Sets 300 seconds (5 minutes) to wait before restoring.
Sets 60 minutes to wait before restoring.
Sets 12 hours to wait before restoring.
Warning dialog box appears. Click the
dialog box appears. Click the
Information
OK button to proceed.
button to proceed.
OK
