Emotron VS10 Operation Instructions Manual page 226

Parameter Name / value range / [default setting]
0x1A01:005 TPDO2 mapping parameter: Application object 5
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
0x1A01:006 TPDO2 mapping parameter: Application object 6
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
0x1A01:007 TPDO2 mapping parameter: Application object 7
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
0x1A01:008 TPDO2 mapping parameter: Application object 8
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
0x1A02:000 TPDO3 mapping parameter: Number of mapped
application objects in TPDO
0 ... [0] ... 8
0x1A02:001 TPDO3 mapping parameter: Application object 1
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
0x1A02:002 TPDO3 mapping parameter: Application object 2
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
0x1A02:003 TPDO3 mapping parameter: Application object 3
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
0x1A02:004 TPDO3 mapping parameter: Application object 4
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
0x1A02:005 TPDO3 mapping parameter: Application object 5
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
0x1A02:006 TPDO3 mapping parameter: Application object 6
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
0x1A02:007 TPDO3 mapping parameter: Application object 7
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
0x1A02:008 TPDO3 mapping parameter: Application object 8
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
226
Info
Mapping entry 5 for TPDO2.
Mapping entry 6 for TPDO2.
Mapping entry 7 for TPDO2.
Mapping entry 8 for TPDO2.
Number of objects mapped in TPDO3.
Mapping entry 1 for TPDO3.
Mapping entry 2 for TPDO3.
Mapping entry 3 for TPDO3.
Mapping entry 4 for TPDO3.
Mapping entry 5 for TPDO3.
Mapping entry 6 for TPDO3.
Mapping entry 7 for TPDO3.
Mapping entry 8 for TPDO3.
01-6203-01R3, CG Drives & Automation
