Appendix

Option for RS-485 Communication
■
RS485 Converter
Available to communicate the PC and the drive. One module per multi -drop link is required.
Type
RS485 to RS232
FAS-RCR
■
RS-232 Connection Cable for FAS-RCR
Universal DB-9 male-female type cable is used.
Item
CGNR-C-1R8F
CGNR-C-003F
CGNR-C-005F
For more information wiring diagram and connector, refer to
■
RS-485 Connection Cable : for Ezi-STEP-PR
Universal RJ-45 (STP:CAT5 category)
Item
CGNR-R-0R6F
CGNR-R-001F
CGNR-R-1R5F
CGNR-R-002F
CGNR-R-003F
CGNR-R-005F
For more information wiring diagram and connector, refer to
For cabling position, refer to
Item Max comm. Speed [bps]
115,200
FAS-RCR
Length
1.8m
3m
5m
straight type cable is used.
Length
60cm
100cm
150cm
200cm
300cm
500cm
⑤ of 「5.2 Controller Configuration 」.
