·This manual describes handling, maintenance, repair, diagnosis and troubleshooting of Ezi-STEP BT. ·Before operating Ezi-STEP BT, thoroughly read this manual. ·After reading the manual, keep the manual near the Ezi-STEP BT so that any user can read the manual whenever needed.
Page 4
Otherwise, an electric shock or a fire may occur. Warning The case of the Ezi-STEP BT is insulated from the ground of the internal circuit by the condenser. Ground the Ezi-STEP BT. Otherwise, an electric shock or a fire may occur.
Page 5
Attention Make all input signals to OFF before supply input voltage to Ezi-STEP BT. The machine may get damaged or the user may get injured by motor operation. All parameter values are set by default factory setting value. Change this value after reading this manual throughly.
※ This is real measured speed that using 100,000 [pulse/rev] encoder. 3. Simple and Compact all-in-one Motor integrated with Drive Saving installation space and ease of wiring by integrating drive circuits on the back side of a stepping motor. www.fastech-motions.com - 6...
4. Ezi-STEP BT Part Numbering 5. Standard Combination Ezi-STEP-BT-42S-BK-□ Unit Part Motor Model Drive Model Number Number Number Ezi-STEP-BT-42S Ezi-STEP-BT-42M Product Name Ezi-STEP-BT-42L Ezi-STEP-BT-42XL Drive Series Type Ezi-STEP-BT-56S Motor & Drive Integrated Ezi-STEP-BT-56M BT : Built In Ezi-STEP-BT-56L Ezi-STEP-BT-86M Ezi-STEP-BT-86L...
Motor Free / Alarm Reset (Photocoupler Input) Output Signals Alarm, Run/Stop (Photocoupler Output) : Up to the resolution of 10,000[ppr], maximum speed can be reached by 3,000[rpm] and with the resolution more than 10,000[ppr], maximum speed shall be reduced accordingly. www.fastech-motions.com - 8...
9. Torque Characteristics of Motor Ezi-STEP-BT-42 series Ezi-STEP-BT-56 series Motor Voltage : Motor Voltage : 42XL 1,000 1,500 2,000 2,500 3,000 1,000 1,500 2,000 2,500 3,000 Speed[rpm] Speed[rpm] Ezi-STEP-BT-86 series Motor Voltage : 86XL 1,000 1,500 2,000 2,500 3,000 Speed[rpm] www.fastech-motions.com - 9...
2) The ambient temperature of the room should be 0℃~50℃. 3) If the temperature of the product case is higher than 50℃, radiate heat of the outside to cool down. 4) Do not install Ezi-STEP BT under direct rays, near magnetic or radioactive objects. www.fastech-motions.com - 10...
12.4 Parameter Setting Connector(CN3) Function Output Input ---- 13. System Configuration ① ② ③ Type Power Cable Signal Cable Parameter Setting Cable Length supplied 30cm Max. Length www.fastech-motions.com - 12...
13.1 Options ① Power Cable ③ Parameter Setting Cable Available to connect between PC and Ezi-STEP BT. Available to connect between Power and Ezi-STEP BT. This is used for change setting value of Resolution and Item Length [m] Remark Stop Current etc.
(For details, please refer to Control Signal Input/Output Description) ※ When connects I/O cable between controller and drive, please turn off the power of both controller and drive, in order to protect the drive from any damage. www.fastech-motions.com - 14...
(For details, please refer to Control Signal Input/Output Description) ※ When connects I/O cable between controller and drive, please turn off the power of both controller and drive, in order to protect the drive from any damage. www.fastech-motions.com - 15...
[ON], cancel Alarm output. Before cancel the Alarm output, have to remove the source of alarm. [Caution] If Alarm Reset input signal still remains [ON], motor will be Free state. Keep in mind to change [ON]→[OFF] state. www.fastech-motions.com - 16...
Resolution, Stop Current, level of Alarm Reset, Alarm, Motion Direction and so on. By using this drive setting program, user can find the optimal condition to Ezi-STEP BT to fit with the user's own system. Please be noticed that connection for drive setting program shall be done when the Ezi-STEP BT is disable staus for safety reason.
CD. It is recommended to make a copy of the pro- gram in any folder on your computer. Then please execute the program, named “Ezi-STEP BT Setting.exe”, from the folder.
※ The default factory setting is Nomal. ※ Caution : When you select ‘Inverse’ : It can be ‘Motor Free’ status when power is applied to Ezi-STEP BT during Signal Connector(CN2) is not connected. The power LED(green) is flash to show the status of ‘Motor Free’...
Appendix Cable for RS-232C ■ For cable extension between PC and Ezi-STEP BT drive. WIRING DIAGRAM Connector of Drive Connector of Motor wiring Pin layout Pin number Pin number Pin layout www.fastech-motions.com - 20...
Page 22
· User manual are subject to change without notice to improve the product or quantitative changes in specifications and user’s manual. · Ezi-STEP is registered trademark of FASTECH Co., Ltd in the national registration ⓒ Copyright 2007 FASTECH Co., Ltd. May 28, 2021 Rev.4...
