11. Communication Function

In case of RS-485, up to 16 axes can be controlled by the multi -drop link(daisy chain).
If Windows goes to the stand -by mode, serial
Caution
basically disconnected. So, after recovering from the stand -by mode,
the user should connect communication again. This content is equally
applied to the library provided with the product.

11.1 Connection with the PC

There are one method
communication). PC's
converters according to each communication type, the user can connect the PC and the
drive module. The maximum communication speed i s 115200[bps] with RS -232 to RS-485
converter.
For connection with the PC, refer to
1) Cable of Connecting RS232 Port (to PC) and Converter (RS232 ↔ RS-485)
Normally Power does not need to be supplied to the converter module. But when
the communication have problems without power, DC 5~24V external power can connect.
The signal is wired as follows.
of connecting the
RS-232C port is used.
RS-485 Converter (to RS -232)
「5.2 Controller
www.fastech.co.kr
11. Communication Function
communication is
drive and the PC by
By using following
Configuration」.
52
RS-485(serial
communication
