10. Other Operation Functions

10.1 Position Table(PT) Operation Example

Input 'PT A0~ PT A7' signals to set PT number. Input 'PT Start'number to execute
speed control operation. For more information, refer to
Function」.
【Position Table Setting 】
PT Command
No. type
0 3
1 3
2 3
3 3

10.2 Jog Operation Example

The machine executes speed control operation at the speed set by parameters according to
inputting 'Jog+' and 'Jog-' signals.
【Parameter Setting 】
No.
6
7
8
Jog+
Command
Jog-
Command
Low High
Position
Speed Speed
10000 1 2500
1000 1 500
5000 1 1500
-2500 1 1000
Parameter Name
Jog Speed
Jog Start Speed
Jog Acc Dec Time
www.fastech.co.kr
10. Other Operation Functions
「User Manual – Position Table
Accel. Decel. Wait
time time time
50 300 0
- - 0
50 300 300
300 300 0
Setting Value Unit
1500 [pps]
100 [pps]
200 [msec]
47
Continuous JP Table
Action No.
1 1
1 2
0 3
0 -
