6.8 I/O Signal Connector (CN1)
Input/output signal connector ( Connector Type : 3M 10226-5A2JL)
The input/output pin is set by using user program(GUI) or DLL library.
programmable
Connect the Brake (current consumption is under 200[mA]) for pin 24.
Caution
Refer to
Function
LIMIT+ (Dedicated Input)
LIMIT- (Dedicated Input)
ORIGIN (Dedicated Input)
Digital In1 (Programmable Input )
Digital In6 (Programmable Input )
Digital In7 (Programmable Input )
Compare Out (Dedicated Output )
Digital Out1 (Programmable Output )
Digital Out2 (Programmable Output )
Digital Out3 (Programmable Output )
Digital Out4 (Programmable Output )
Digital Out5 (Programmable Output )
Digital Out6 (Programmable Output )
* This connector fixed pin is connected to frame GND through a mount hall.
6.9 Communication Connector (CN5)
Connector Type : RJ45
Cable Type : UTP/STP CAT5E
Pin No. Function
1,2,4,5,7,8
3 Data+
6 Data-
case Frame GND
6. External Name and Function Setting of Ezi-STEP-PR
7.4 Output signal for the Brake that is over 200[mA].
No No
1 14
2 15
3 16
4 17
5 18
6 19
7 20
8 21
9 22
10 23
11 24
12 25
13 26
LED No. Display
GND
1,3 RUN
2,4 COMM
www.fastech.co.kr
Function
Digital In2 ( Programmable Input )
Digital In3 ( Programmable Input )
Digital In4 ( Programmable Input )
Digital In5 ( Programmable Input )
Digital In8 ( Programmable Input )
Digital In9 ( Programmable Input )
Digital Out7 ( Programmable Output )
Digital Out8 ( Programmable Output )
Digital Out9 ( Programmable Output )
+24V for brake system( Output )
Control signal of brake system(Output)
GND external(Input)
+24V external(Input)
Color Lighting
Green Flash when CPU in the drive operates
Flash when this communicates with the
Yellow
upper controller
27
