SSANGYONG RODIUS 2005.07 Manual page 448

4. INFLATION OF AIRBAG
▶ Front Airbag Operation (Driver's and Passenger's)
The air bag inflates when:
Frontal impact against a solid concrete wall at over 25 km/h or near-frontal impact
·
within 30 degrees from the center of the vehicle at both corners
The air bag can inflate when:
Underbody impact from the road surface; impact against the curb at a very high speed;
·
dropping impact onto the road surface with a large angle
The air bag does not inflate when:
Rollover, side impact or rear impact
·
The air bag seldom inflates when:
Weak impact in which the sensor is unable to detect (under the inflation requirements)
·
· Impact against narrow objects such as a telegraph pole or a tree
The vehicle falls into a drainage or a puddle
·
The front of the vehicle crashes into high impact point vehicle such as a truck
·
· Impact on the hood by falling stones
The air bag warning lamp is on
·
0-11
8810-01
AIR BAG SYSTEM
RODIUS 2005.07
