2. STRUCTURE
1.
Torque converter
2.
Oil pump
3.
Input shaft
4.
Disc brake B1
5.
Disc clutch C1
6.
Disc clutch C2
DC 5-SPEED AUTOMATIC TRANSMISSION
RODIUS 2005.07
7.
Disc brake B3
8.
Disc clutch C3
9.
Disc brake B2
10.
Output shaft
11.
Parking lock gear
12.
Intermediate shaft
13.
Freewheel F2
14.
Center planetary gear set
15.
Electric control unit (valve body)
16.
Freewheel F1
17.
Stator shaft
18.
Converter lockup clutch
