0-32
8710-01
(5) Auto Door Unlock (Crash Unlock)
For conventional vehicles, G-sensor in RK STICS generates "UNLOCK"
collided over 15 km/h over vehicle speed. In this vehicle, the factory installed air bag module
transmits the collision signal to STICS to unlock the door.
1.
The air bag collision signal cannot be accepted within 7 seconds after turning the ignition
key to "ON" position.
After this period, the door lock system outputs "UNLOCK" for all doors for 5 seconds
2.
(T2) from 0.4 seconds (T2) after receiving the air bag collision signal.
Even though the key is turned to "OFF" position during the output of "UNLOCK", the
3.
output continues on for remaining period.
After input of the air bag collision signal, the door lock system doesn't output
4.
"UNLOCK" even when turning the ignition key to "ON" position.
The "Unlock" control by air bag signal prevails over any "LOCK" or "UNLOCK"
(1)
control by other functions.
The "LOCK/UNLOCK" request by other functions will be ignored after/during the
(2)
output of "UNLOCK" by the air bag.
However, the door lock is controlled by other functions when IGN1 SW is "OFF"
IGN2 SW is "OFF".
If the door lock system outputs "LOCK"
(3)
"LOCK" output can be activated.
Even though the "LOCK/UNLOCK" output is requested, the door lock system cannot
(4)
output "LOCK/UNLOCK" when all door lock switches are locked/unlocked.
Also, even though the "UNLOCK" output for the driver's door is requested, the door
lock system cannot output "UNLOCK"
STICS
RODIUS 2005.07
and "UNLOCK" simultaneously, only the
when the driver's door is unlocked.
signal when
and
