Demonstration architecture overview
2.3
USB console
The USB console frame window shows the USB Host connectivity state. The USB Disk
Flash Connected message means that the USB Flash disk is configured and ready for use.
Figure 8.
2.4
System info
The system info sub-demo is composed of three window frames. The user can use the
forward and back buttons to navigate within the three windows while the Exit button ends the
sub-demo and displays the main menu (Icon view).
The first frame window
STM32 hardware resources (RAM and Flash size).
Figure 9.
10/21
USB console frame window
(Figure
9) shows the hardware and software revisions and the
First frame window
Doc ID 018665 Rev 3
UM1069
