Analog clock

The analog clock window shows the system clock (RTC) on an analog background, and also
the current date on the caption of the frame window.

Figure 21. Analog clock window

To configure the clock and the date, the user can click the Set button to display a second
frame window with a numerical pad used to easily set the clock and the date.

Figure 22. Analog clock configuration window

The date and the clock display use the following format.

Figure 23. Analog clock date and time format

If the format is not correct, an error message
re-enter a valid value.

Figure 24. Analog clock error message

Time: hh:mm:ss
Date: dd\mm\yyyy
