Demonstration architecture overview
The user can enable/disable the automatic slide show by clicking on the picture; when the
automatic slide show is enabled, the images are changed every second.
The user can also select the image to show from the list displayed in the right of the Image
browser window frame.
Table 3 shows the different supported BMP formats.
Table 3.
Bits per pixel
2.6

Web server

This demonstration is an embedded web server based on the lwIP stack. It allows
addressing the STM3220G-EVAL board as a web page using your web browser to control
the four LEDs on the board and the potentiometer level.
The STM32 Ethernet peripheral is configured in MII mode with speed auto negotiation and
the Clock for the external PHY is provided by the STM32 through the MCO pin.

Figure 13. Web server DHCP server reply

The web server sub-demo supports the DHCP protocol and, if the DHCP is enabled in the
host side, an automatic IP address is assigned to the board; otherwise, a static IP address is
used instead (192.168.0.8).
12/21
Supported bitmap formats
Indexed
1
4
4
8
8
16
24
32
Doc ID 018665 Rev 3
Compression
Yes
Yes
Yes
Yes
Yes
No
No
No
Supported
No
No
Yes
No
Yes
No
No
No
UM1069
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
