NOTE! Do not put any objects in the foot area in front of the
6
child seat.
• Release the lock of the ISOFIX connectors. Both locks
can be adjusted independently. Push both buttons (5
and 6) simultaneously and pull the ISOFIX connectors
out of the base to the endstopper.
• The ISOFIX connectors (7) have to lock into the ISOFIX
anchorage points (2) with an audible click.
• Make sure that the seat stays firmly in place by trying to
pull it out of the ISOFIX connect guides.
• The green safety indicator (8) must be clearly visible on
both ISOFIX release buttons.
• Next, push the base in the direction to the backrest until it
8
is fully aligned with the backrest.
• You can now carry on with the chapter, "ADJUSTING
THE SUPPORTING LEG".
NOTE! It is possible that some car seats that are made
of soft material (e.g. velour, leather, etc.) may show signs
of usage and/or discoloration. In order to avoid this, you
could for example, place a cover or towel underneath it. In
this context we would also like to refer you to our cleaning
instructions, which must be absolutely followed before the
first use of the seat.
