INSTALLATION OF THE CHILD SEAT

NOTE! If your car is not equipped with an i-Size seating
position, please check the typelist attached to the product.
The ISOFIX system allows you to fit the CYBEX SIRONA
M2 i-Size securely into the car.
Installing the Base
• Select an authorised car seat.
NOTE! The ISOFIX anchorage points (2) are two metal
lugs per seat and are located between the backrest and the
seat of the car. If you are in any doubt, consult your car's
instruction manual for assistance.
• If the ISOFIX anchorage points (2) in your car are
difficult to access, you should use the connect guides (3)
provided in order to avoid damaging the cover.
4
• If necessary attach the connect guides (3) provided
with the longer lug pointing upwards into both ISOFIX
anchorage points (2). In many cars it is more effective to
install the connect guides (3) in an opposing direction.
• Always fold out the supporting leg (4) until it locks.
