Bit Name
17 ICFEMPTY1
Set when input capture FIFO is empty
16 ICFEMPTY0
Set when input capture FIFO is empty
15:11 Reserved
10 OCBV2
This field indicates that the TIMERn_CCx_CCVB registers contain data which have not been written to
TIMERn_CCx_CCV. These bits are only used in OUTPUTCOMPARE or PWM mode and are cleared when CCMODE is
written to 0b00 (Off).
9 OCBV1
This field indicates that the TIMERn_CCx_CCVB registers contain data which have not been written to
TIMERn_CCx_CCV. These bits are only used in OUTPUTCOMPARE or PWM mode and are cleared when CCMODE is
written to 0b00 (Off).
8 OCBV0
This field indicates that the TIMERn_CCx_CCVB registers contain data which have not been written to
TIMERn_CCx_CCV. These bits are only used in OUTPUTCOMPARE or PWM mode and are cleared when CCMODE is
written to 0b00 (Off).
7 Reserved
6 SYNCBUSY
Indicates synchronization ongoing
5 DTILOCKSTATUS
Indicates current status of DTI lock
Value
0
1
4 TIMERLOCKSTATUS
Indicates current status of Timer lock
Value
0
1
3 Reserved
2 TOPBV
This indicates that TIMERn_TOPB contains valid data that has not been written to TIMERn_TOP. This bit is also cleared
when TIMERn_TOP is written.
1 DIR
Indicates count direction.
Value
silabs.com | Building a more connected world.
Reset Access Description
0x0 R Input capture fifo empty
0x0 R Input capture fifo empty
To ensure compatibility with future devices, always write bits to 0. More information in
ventions
0x0 R Output Compare Buffer Valid
0x0 R Output Compare Buffer Valid
0x0 R Output Compare Buffer Valid
To ensure compatibility with future devices, always write bits to 0. More information in
ventions
0x0 R Sync Busy
0x0 R DTI lock status
Mode Description
UNLOCKED DTI registers are unlocked
LOCKED DTI registers are locked
0x0 R Timer lock status
Mode Description
UNLOCKED TIMER registers are unlocked
LOCKED TIMER registers are locked
To ensure compatibility with future devices, always write bits to 0. More information in
ventions
0x0 R TOP Buffer Valid
0x0 R Direction
Mode Description
Reference Manual
TIMER - Timer/Counter
1.2 Con-
1.2 Con-
1.2 Con-
