19.4 Register Map

The offset register address is relative to the registers base address.
Offset Name
0x000 TIMER_IPVERSION
0x004 TIMER_CFG
0x008 TIMER_CTRL
0x00C TIMER_CMD
0x010 TIMER_STATUS
0x014 TIMER_IF
0x018 TIMER_IEN
0x01C TIMER_TOP
0x020 TIMER_TOPB
0x024 TIMER_CNT
0x02C TIMER_LOCK
0x030 TIMER_EN
0x060 TIMER_CCx_CFG
0x064 TIMER_CCx_CTRL
0x068 TIMER_CCx_OC
0x070 TIMER_CCx_OCB
0x074 TIMER_CCx_ICF
0x078 TIMER_CCx_ICOF
0x0E0 TIMER_DTCFG
0x0E4 TIMER_DTTIMECFG
0x0E8 TIMER_DTFCFG
0x0EC TIMER_DTCTRL
0x0F0 TIMER_DTOGEN
0x0F4 TIMER_DTFAULT
0x0F8 TIMER_DTFAULTC
0x0FC TIMER_DTLOCK
0x1000 TIMER_IPVERSION_SET
0x1004 TIMER_CFG_SET
0x1008 TIMER_CTRL_SET
0x100C TIMER_CMD_SET
0x1010 TIMER_STATUS_SET
0x1014 TIMER_IF_SET
0x1018 TIMER_IEN_SET
0x101C TIMER_TOP_SET
0x1020 TIMER_TOPB_SET
silabs.com | Building a more connected world.
Type Description
R IP version ID
RW CONFIG Configuration Register
RW SYNC Control Register
W SYNC Command Register
RH Status Register
RWH INTFLAG Interrupt Flag Register
RW Interrupt Enable Register
RWH SYNC Counter Top Value Register
RW SYNC Counter Top Value Buffer Register
RWH SYNC Counter Value Register
W TIMER Configuration Lock Register
RW ENABLE module en
RW CONFIG CC Channel Configuration Register
RW SYNC CC Channel Control Register
RWH SYNC OC Channel Value Register
RW SYNC OC Channel Value Buffer Register
R(r)H IC Channel Value Register
RH SYNC IC Channel Value Overflow Register
RW CONFIG DTI Configuration Register
RW CONFIG DTI Time Configuration Register
RW CONFIG DTI Fault Configuration Register
RW SYNC DTI Control Register
RW SYNC DTI Output Generation Enable Register
RH DTI Fault Register
W SYNC DTI Fault Clear Register
W DTI Configuration Lock Register
R IP version ID
RW CONFIG Configuration Register
RW SYNC Control Register
W SYNC Command Register
RH Status Register
RWH INTFLAG Interrupt Flag Register
RW Interrupt Enable Register
RWH SYNC Counter Top Value Register
RW SYNC Counter Top Value Buffer Register
