13.5.52 PRS_CONSUMER_TIMER2_CC0 - TIMER2 CC0 Consumer Selection

Offset
0x14C
Reset
Access
Name
Bit Name
31:10 Reserved
9:8 SPRSSEL
Select which synchronous PRS channel routes to this consumer.
7:4 Reserved
3:0 PRSSEL
Select which asynchronous PRS channel routes to this consumer.

13.5.53 PRS_CONSUMER_TIMER2_CC1 - TIMER2 CC1 Consumer Selection

Offset
0x150
Reset
Access
Name
Bit Name
31:10 Reserved
9:8 SPRSSEL
Select which synchronous PRS channel routes to this consumer.
7:4 Reserved
3:0 PRSSEL
Select which asynchronous PRS channel routes to this consumer.
silabs.com | Building a more connected world.
Bit Position
Reset Access Description
To ensure compatibility with future devices, always write bits to 0. More information in
ventions
0x0 RW Synchronous Channel Selection
To ensure compatibility with future devices, always write bits to 0. More information in
ventions
0x0 RW Asynchronous Channel Selection
Bit Position
Reset Access Description
To ensure compatibility with future devices, always write bits to 0. More information in
ventions
0x0 RW Synchronous Channel Selection
To ensure compatibility with future devices, always write bits to 0. More information in
ventions
0x0 RW Asynchronous Channel Selection
Reference Manual
PRS - Peripheral Reflex System
1.2 Con-
1.2 Con-
1.2 Con-
1.2 Con-
Rev. 0.4 | 333
